Home » Products » Use for SAMSUNG » TV-022 Led tv backlight strip use for samsung-40EH led backlight Samsung Curve SVS40-2U13I12-3V1W 13+12led UN39FH5000F,UA39EH5003R

TV-022 Led tv backlight strip use for samsung-40EH led backlight Samsung Curve SVS40-2U13I12-3V1W 13+12led UN39FH5000F,UA39EH5003R

Share to:

TV-022 Led tv backlight strip use for samsung-40EH led backlight Samsung Curve SVS40-2U13I12-3V1W 13+12led UN39FH5000F,UA39EH5003R

Color:	Cold white
Model Number:	40inch
Specification:	3pcs/set
Availability:

Quantity:



Inquire Add to Basket

Model:
samsung-40EH

Type	Led Backlight
Original code	LUMENS D3GE-390SMA-R2 13.07.10 LUMENS D3GE-390SMB-R2 13.07.10 SAMSUNG_2013SVS39_T2_3228N1_B2_12_REV1.7_131015 SAMSUNG_2013SVS39_T1_3228N1_B2_13_REV1.7_131015
Compatible Model	UN39FH5000F,UA39EH5003R,HG39AB460H,UN39FH5000FXZX,UA39EH5003RXXV,UA39FH5003RXXM,UA39FH5003RXXD,UA39EH5003RXRQ,UA39EH5003RLXL,UA39EH5003MXXS
Compatible Brand	For Samsung
Color	Cold White
Application	TV Sets
Size	12LEDS: 734mm 13LEDs: 742mm
Material	Aluminum PCB
LED Qty	13+12led
Voltage	3V/Led
Lamp Power	1W/Led
LM/Led	110-120LM
ColorTemperature(CCT)	12000-30000k
Warranty	2 years
Working Lifetime(Hour)	50000
